MikroTik hEX E50UG Router

The MikroTik hEX E50UG is the refreshed version of the classic hEX wired router, combining the familiar compact design with upgraded hardware for significantly improved performance.

The MikroTik hEX Refresh features a modern dual-core ARM processor, 512MB RAM and RouterOS v7, while retaining five Gigabit Ethernet ports, USB connectivity and passive PoE input.

Designed for homes, offices and small business networks, the MikroTik E50UG Router provides a powerful and affordable platform for advanced wired networking.

MikroTik hEX Refresh — More Performance

The new MikroTik hEX E50UG brings a major hardware upgrade to the established hEX platform.

Compared with the previous generation, the hEX Refresh increases:

• RAM from 256MB to 512MB
• Modern ARM-based CPU
• RouterOS v7
• Updated hardware architecture

According to MikroTik’s published information, performance improvements can reach approximately 100–134% depending on the configuration.

This makes the MikroTik hEX Refresh suitable for users who want additional processing capability without moving to a larger or more expensive router.

---

Dual-Core ARM Processor

The MikroTik E50UG is powered by an EN7562CT dual-core ARM processor running at 950 MHz.

The modern ARM architecture provides the processing platform required for RouterOS v7 and advanced networking configurations.

CPU Specifications

• CPU: EN7562CT
• Architecture: ARM 32-bit
• CPU cores: 2
• CPU frequency: 950 MHz
• CPU threads: 2

Combined with 512MB RAM, the hardware is designed to handle routing, firewall rules, queues and other RouterOS functions.

---

512MB RAM

One of the biggest hardware improvements in the MikroTik hEX E50UG is the increase to 512MB RAM.

The previous hEX hardware used 256MB RAM, while the refreshed E50UG provides twice the memory capacity.

The additional RAM provides more resources for RouterOS and advanced networking configurations.

This makes the MikroTik hEX Refresh an attractive option for users who want a compact router with a more modern hardware platform.

---

5 Gigabit Ethernet Ports

The MikroTik hEX E50UG Router includes five 10/100/1000 Gigabit Ethernet ports.

These ports can be used to connect:

• Desktop computers
• Laptops
• Network switches
• Servers
• NAS devices
• IP cameras
• Access points
• Other Ethernet networking equipment

The five-port configuration makes the MikroTik E50UG suitable for connecting multiple wired devices without immediately requiring an additional switch.

---

RouterOS v7

The MikroTik hEX E50UG comes with RouterOS v7 pre-installed and a Level 4 RouterOS license.

RouterOS provides a wide range of professional networking features.

Depending on your configuration, the E50UG can be used for:

• Advanced routing
• Firewall
• NAT
• DHCP
• DNS
• VLAN
• VPN
• IPsec
• Bandwidth management
• Traffic shaping
• Queue management
• Network monitoring
• Bridge configuration
• Routing protocols
• User access control

The operating system and license are already included, so there is no separate RouterOS license purchase required.

---

USB Port for Additional Storage

The MikroTik hEX Refresh E50UG includes a full-size USB Type-A port.

The USB port can be used with compatible devices and RouterOS-supported applications. Additional storage can also be useful for certain file-sharing and media-related applications.

The USB interface supports up to 1A current according to the published specifications.

---

Passive PoE Input

The MikroTik E50UG Router supports passive PoE-IN, providing an alternative method of powering the device.

The router supports:

• DC jack input
• Passive PoE input

The supported input voltage range is 12–28V.

This provides flexibility for network installations where PoE-based power delivery is preferred.

---

Compact Design

The MikroTik hEX E50UG maintains the compact design associated with the hEX series.

Its dimensions are:

113 × 89 × 28 mm

The compact enclosure makes it suitable for:

• Home networks
• Small offices
• Network cabinets
• Small business installations
• Network labs
• ISP customer installations

The device uses passive cooling, so there is no active cooling fan.

---

Low Power Consumption

The MikroTik hEX Refresh is designed as a relatively low-power wired router.

Its published maximum power consumption is approximately 10W, while power consumption without attachments is approximately 4W.

This makes it suitable for installations where efficient power usage is important.

---

MikroTik hEX E50UG for Home Networks

The MikroTik hEX E50UG can serve as a central wired router for home networks.

It can manage internet connectivity and provide wired connections to computers, smart TVs, NAS devices, access points and other network equipment.

Because it runs RouterOS v7, users can configure more advanced networking features than are normally available on basic consumer routers.

---

MikroTik hEX E50UG for Small Offices

For small offices and businesses, the MikroTik hEX Refresh can provide a compact platform for:

• Internet routing
• Firewall configuration
• VLANs
• Bandwidth management
• DHCP
• NAT
• VPN
• Network monitoring
• Wired device connectivity

The five Gigabit Ethernet ports provide direct connectivity for multiple network devices.

---

MikroTik hEX E50UG Performance

MikroTik’s published Ethernet testing shows high throughput under controlled laboratory conditions.

In the published routing test without additional processing, the E50UG achieved approximately:

3.65 Gbps at 512-byte packets

under the specified test methodology.

With 25 IP filter rules, the published result was approximately:

1.43 Gbps at 512-byte packets.

The published test results are laboratory measurements using specific hardware and software configurations. Actual throughput can vary depending on packet size, firewall rules, queues, VLANs, VPN configuration and other RouterOS features.

---

IPsec Performance

The MikroTik hEX E50UG also supports hardware-assisted IPsec.

According to the published testing, a single AES-128-CBC + SHA1 IPsec tunnel achieved approximately:

351.7 Mbps at 1400-byte packets

under the specified test configuration.

For 256 tunnels, the published results vary according to the encryption configuration.

Actual VPN performance depends on encryption algorithms, packet size, number of tunnels and other network processing requirements.

---

MikroTik hEX E50UG Specifications

---

Key Features of MikroTik hEX E50UG

Modern ARM Dual-Core CPU

The E50UG uses a dual-core 950 MHz ARM processor for improved processing capability.

512MB RAM

The refreshed hEX doubles the RAM compared with the previous 256MB version.

5 Gigabit Ethernet Ports

Five Gigabit Ethernet ports provide high-speed wired network connectivity.

RouterOS v7

Advanced routing, firewall, VLAN, VPN, traffic management and other networking functions are available through RouterOS v7.

USB Type-A

The full-size USB port provides additional connectivity and storage options.

Passive PoE-IN

The router supports passive PoE input as an alternative power source.

Compact Design

Its small 113 × 89 × 28 mm enclosure is suitable for space-constrained installations.

Passive Cooling

The E50UG uses passive cooling for a simple, fanless design.

---

Why Choose MikroTik hEX E50UG?

The MikroTik hEX E50UG combines the familiar hEX concept with substantially upgraded hardware.

Its key advantages include:

• 512MB RAM
• Dual-core ARM CPU
• RouterOS v7
• 5 Gigabit Ethernet ports
• USB Type-A
• Passive PoE input
• Compact form factor
• Low power consumption
• Advanced MikroTik networking features

For users looking for an affordable MikroTik Gigabit router with modern ARM hardware, the hEX Refresh E50UG provides a practical wired networking solution.

---

Buy MikroTik hEX E50UG in Pakistan

Looking to buy MikroTik hEX E50UG in Pakistan?

Universal Fiber Solutions provides networking and fiber-optic solutions for homes, offices, businesses, ISPs and professional network installations.

The MikroTik hEX Refresh E50UG is suitable for customers looking for a 5-port Gigabit router with 512MB RAM, dual-core ARM CPU, USB, passive PoE and RouterOS v7.

Contact Universal Fiber Solutions for MikroTik E50UG price in Pakistan, availability and networking requirements.
