Eloik ALK-88 Fusion Splicing Machine
+ Free ShippingThe Eloik ALK‑88 Fusion Splicer is a professional four‑motor core alignment machine designed for FTTH, telecom, and backbone fiber projects. With 7‑second splicing, 14‑second heating, and a 5200mAh battery supporting 200+ cycles, it delivers ultra‑low splice loss, titanium alloy durability, and stable performance in harsh environments. Available now at Universal Fiber Solutions (UFS) — the trusted place to buy Eloik ALK‑88 fusion splicers online at the best price.
Overview
The Eloik ALK‑88 Optical Fiber Fusion Splicer, distributed by Universal Fiber Solutions (UFS), is engineered for precision, speed, and durability. Featuring core alignment technology, it delivers 7‑second splicing and 14‑second heating cycles.
Its titanium alloy body, anti‑shock design, and multi‑layer waterproof/dustproof protection make it ideal for telecom operators, FTTH projects, and backbone fiber deployments.
⚡ Key Features
- 7‑second fast splicing – ultra‑efficient performance
- 14‑second heating – customizable heating cycles
- Four‑motor core alignment – super precision 0.1µm
- High‑capacity battery – 5200mAh, supports 200+ cycles per charge
- Durable build – titanium alloy body, waterproof, dustproof, windproof, anti‑shock protection
- 4.3‑inch LCD display – high‑resolution touchscreen interface
- Automatic fiber identification – smart detection and heating when cover closes
- Multi‑language support – Chinese, English, Russian, Portuguese, French, Spanish, Italian, Polish, Thai
- Electrode life – ≥5000 discharges
- USB port – data management and PC software upgrade
📊 Technical Specifications
| Parameter | Details |
|---|---|
| Fiber alignment | Core alignment, cladding alignment, fine alignment |
| Splicing time | 7s (fast mode), 9s (typical mode) |
| Heating time | 14s (customizable) |
| Fiber types | SMF/G.652, MMF/G.651, DSF/G.653, NZ‑DSF/G.655, BIF/G.657, EDF |
| Splicing loss | 0.02dB (SM), 0.01dB (MM), 0.04dB (DS/NZDS), 0.02dB (BI) |
| Display | 4.3‑inch color LCD |
| Battery | 5200mAh, >200 cycles per charge |
| Magnification | 180x dual axis / 350x single axis |
| Protection | Waterproof, dustproof, windproof, anti‑shock |
| Operating environment | ‑20°C to +55°C, ≤95%RH, altitude ≤5000m |
📦 Standard Package
- ALK‑88 Fusion Splicer (Main Unit)
- Fiber cleaver
- Power adapter + AC power cord
- Electrodes
- Cooling tray
- Miller stripper + rubber‑insulated fiber stripper
- Multi‑function fixture
- Carrying case
- Dust‑blowing ball + brush
- Plastic tweezers
- Instruction manual
- Alcohol bottle
- Optional fixtures: FC/LC/SC, car charger, aerial working platform
🛡️ Service Commitment
Purchasing the Eloik ALK‑88 Fusion Splicer from UFS includes:
- 3‑year warranty (excluding consumables like electrodes, cleaver blades, and stripping tools)
- Professional support and authorized servicing
- Commitment to industry‑standard quality and reliability
