SC/UPC Waterproof Fiber Optic Adapter

SC/UPC Waterproof Fiber Optic Adapter

The SC/UPC Waterproof Adapter provides a secure and reliable fiber connection for harsh outdoor environments. Its sealed waterproof housing protects the fiber connection from dust and water while maintaining stable optical performance.

Designed for Singlemode OS2 fiber, this adapter is suitable for FTTH, FTTx, CATV, telecom, and outdoor communication networks.

Waterproof & Rugged Design

The adapter features IP67/IP68-rated protection against dust and water ingress. A sealing gasket and protective dust cap help keep the connection protected in demanding outdoor conditions.

Its operating temperature range of –40°C to +85°C makes it suitable for a wide range of outdoor installations.

Low-Loss Fiber Connection

A high-precision zirconia ceramic sleeve helps maintain accurate fiber alignment and stable signal transmission. The adapter provides insertion loss ≤0.2dB and return loss ≥50dB.

The stainless steel clip provides secure internal mounting, while the adapter is rated for 1000 plug cycles.

Technical Specifications

• Adapter Type: SC to SC Simplex
• Fiber Type: Singlemode
• Fiber Compatibility: OS2
• Polish Type: UPC
• Color: Blue
• Protection: IP67 / IP68
• Sleeve: Zirconia Ceramic
• Clip: Stainless Steel
• Housing: Waterproof
• Protection Features: Dust Cap & Sealing Gasket
• Insertion Loss: ≤0.2dB
• Return Loss: ≥50dB
• Durability: 1000 Plug Cycles
• Operating Temperature: –40°C to +85°C
• Outer Sheath: Low Smoke Zero Halogen (LSZH)

Key Benefits

• IP67/IP68 waterproof protection
• Designed for outdoor and industrial use
• Compatible with OS2 singlemode fiber
• Low insertion loss
• High return loss
• Precision zirconia ceramic sleeve
• Protective dust cap and sealing gasket
• Wide operating temperature range
• Durable up to 1000 plug cycles

Applications

• FTTH Networks
• FTTx Networks
• CATV Networks
• Outdoor Telecom Networks
• Outdoor Fiber Distribution
• Industrial Communication
• Fiber Enclosures
• Harsh Environment Installations
• Outdoor Network Cabinets

Buy SC/UPC Waterproof Adapter in Pakistan

Looking to buy SC/UPC Waterproof Adapter in Pakistan? Universal Fiber Solutions (UFS) supplies reliable fiber optic connectivity products for FTTH, FTTx, CATV, telecom, ISP, and outdoor networking projects.

Warranty & Support

Warranty: Subject to applicable terms
Technical Support: Available from Universal Fiber Solutions (UFS)
