Jet Fiber H5 Splicing Machine
+ Free ShippingThe JetFiber H5 Fusion Splicer is a lightweight, handheld core alignment machine designed for FTTH installations, telecom projects, and security monitoring. With 5‑second splicing, 12‑second heating, and a 4000mAh battery supporting 240+ cycles, it delivers ultra‑fast, stable, and low‑loss performance. Available now at Universal Fiber Solutions (UFS) — the trusted place to buy JetFiber H5 fusion splicers online at the best price.
Overview
The JetFiber H5 Optical Fiber Fusion Splicer, distributed by Universal Fiber Solutions (UFS), is engineered for speed, portability, and precision. Featuring core alignment technology, it delivers 5‑second splicing and 12‑second adjustable heating cycles.
Its compact 1.5kg design, auto‑calibrated ARC discharge, and intelligent time‑lock function make it ideal for telecom operators, FTTH projects, and emergency fiber repairs.
⚡ Key Features
- Ultra‑fast performance – 5s splicing, 12s heating
- Compact design – handheld, lightweight at only 1.5kg (1.8kg with battery)
- High‑capacity battery – 4000mAh, supports 240+ cycles per charge
- Precision alignment – core alignment with single fiber splice mode
- Durable build – waterproof, dustproof, windproof, and anti‑shock protection
- 4.1‑inch color screen – clear fiber view with dual 300x cameras
- USB + Bluetooth interface – supports external LED lighting, mobile charging, and remote app integration
- Data storage – up to 20,000 splice records with export capability
📊 Technical Specifications
| Parameter | Details |
|---|---|
| Fiber alignment | Core alignment |
| Splicing mode | Single fiber |
| Splicing time | 5s |
| Heating time | 12s (adjustable) |
| Fiber types | SMF/G.652, MMF/G.651, DSF/G.653, NZ‑DSF/G.655, BIF/G.657 |
| Splicing loss | 0.02dB (SM), 0.01dB (MM), 0.04dB (DS/NZDS), 0.02dB (BI) |
| Display | 4.1‑inch high‑light color screen |
| Battery | 4000mAh, >240 cycles per charge |
| Magnification | 300x single axis / 150x dual axis |
| Protection | Waterproof, dustproof, windproof, anti‑shock |
| Operating environment | ‑20°C to +50°C, ≤95%RH, altitude ≤5000m |
🔧 Built‑in Functions
- Auto‑calibrated ARC discharge – reduces splice loss and improves efficiency
- Time lock function – secure equipment management
- USB + Bluetooth interface – external LED lighting, mobile charging, and remote control
- Mobile app integration – remote monitoring, splice records, and software upgrades
🛡️ Service Commitment
Purchasing the JetFiber H5 Fusion Splicer from UFS includes:
- Warranty coverage (battery, adapter, and consumables per manufacturer policy)
- Professional support and authorized servicing
- Commitment to industry‑standard quality and reliability
| Color | Aqua |
|---|
